    2 Axes Excavator Grab Rotary Welding Positioners 2000KG 250mm

    Ask Lasest Price
    Brand Name : weldsuccess
    Model Number : HBC-20
    Certification : CE
    Price : negotiable
    Supply Ability : 10sets/month
    Delivery Time : 25days
    • Product Details
    • Company Profile

    2 Axes Excavator Grab Rotary Welding Positioners 2000KG 250mm

    2 Axes Rotary Welding Positioners for Excavator Grab / Bucket Welding , Construction Machinery Welding


    1. Main Parameters

    ModelHBC-20
    Rated Load and Rotation2000KG
    Max eccentricity distance250mm
    Max gravity center distance300mm
    Tilting speed (rpm)1
    Rotation speed (rpm)1
    Rotation radius(mm)1900
    Min rotation center height(mm)850
    Machine height(mm)3300
    Tilting angle±360°
    Rotation angle360°
    Rotation motor power1.5KW (brake motor, whole copper wire)
    Tilting motor power3KW (brake motor, whole copper wire)
    Conducting current500A
    Control methodWireless type remote control box

    2. Introduction

    Welding positioner is a kind of auxiliary equipment for welding, grinding or assembling positioning and rotation, which is widely used in metal works, pressure vessel, steel structure, engineering machinery, boiler, heat exchanger, steel structure, chemical, etc.


    2 Axes Free Rotary Welding Positioners have universal applications in the manual and automatic welding of circumferential seams and in the accurate positioning of work-pieces.
